China manufacturer offering stainless welded mesh Roll with1/2inch,1inch,3/4 inch,1/4in,with 1.6mm,1.2mm,3/8in with 1.0mm and more specifications listed

Stainless Steel Welded wire Mesh Rolls

The Stainless Steel Welded Wire Mesh is producting of  SS wire to Welded for The mesh , The hole or mesh smooth ,nice surface and strong structural .Never no rust .better than galvanied welded wire mesh. The Small wire dia. can done the roll mesh ,Called Stainless Steel
welded mesh . The Large wire dia. ,can welded the panel  or sheet  ,then named Stainless Steel welded wire mesh panel or Stainless Steel welded mesh sheet  .
The Stainless steel welded mesh sheet Having no cracks or pours to harbour dirt or bacteria, the smooth surface of stainless steel gives it excellent hygiene properties, so it is also often used in the food and catering industry, Ultrasonic cleaning mechanical
equipment,washing and cheaning industrial ,as well as the health services. The mechanical resistance of stainless steel makes it durable to scratching and other damage, providing it with it aesthetically attractive appearance, and giving it low maintenance properties.
Material : stainless steel wire SS201.SS202.SS302.SS304. SS 304L .SS 316 SS 316L



Wire Diam





1/4" × 1/4"

6.4mm × 6.4mm

16# - 24#

0.7mm - 1.6mm

3/8" × 3/8"

10.6mm × 10.6mm

19# - 22#

1.0mm - 0.7mm

1/2" × 1/2"

12.7mm × 12.7mm

16# - 23#

1.6mm - 0.6mm

5/8" × 5/8"

16mm × 16mm

18# - 21#

1.2mm - 0.8mm

3/4" × 3/4"

19.1mm × 19.1mm

16# - 21#

1.6mm - 0.8mm

1" × 1/2"

25.4mm × 12.7mm

16# - 20#

1.6mm - 0.9mm

1" × 1"

25.4mm × 25.4mm

14# - 21#

2.0mm - 0.8mm

11/2" × 11/2"

38mm × 38mm

14# - 19#

2.0mm - 1.0mm

1" × 2"

25.4mm × 50.8mm

14# - 16#

2.0mm - 1.6mm

2" × 2"

50.8mm × 50.8mm

12# - 16#

2.6mm - 1.6mm

Technical Note:
1,Standard roll length: 30m;width: 0.5m to 2.5m
2,Special sizes available at request
3,Packing: in waterproof paper in rolls. Custom packing available at request

Special specifications can be customized.

Characteristics:It has the good property of corrosion-resisting and oxidation-resisting
Usage: It is widely used on the industry, agriculture, building, transportation, mine, field, lawn, cultivation, Profession’s guard,decorate, machie protection etc.
